PREPREG CARBON TUBES (winding technology)

These are carbon textiles pre-impregnated with resin (known as pre-pregs), which are wound around steel mandrels that are removed after curing in the oven.

This manufacturing process produces materials with good structural mechanical properties whilst also offering an attractive appearance (either matt or glossy).

Standard dimensions

3.04.05.06.07.08.0
9.010.11.012.013.014.0
15.016.017.018.019.020.0
21.022.023.024.025.026.0
27.028.029.030.031.032.0
33.034.035.036.037.038.0
39.040.041.042.043.044.0
45.046.047.048.050.052.0
54.055.056.057.065.067.0
76.077.096.0

The data for CFP profiles may vary depending on the type of fibre reinforcement, shape and wall thickness.

Carbon profile type pultrudedPull-windingPrepreg
ZXZXZX
Tensile strength1,700 MPa80 MPa1,700 MPa80 MPa750 MPa700 MPa
Flexural strength1,700 MPa1,600 MPa300 MPa300 MPa
I.L.S.S. – interlaminar shear strength68 MPa70 MPa
Modulus of elasticity (tensile strength)115 GPa110 GPa60 MPa60 MPa
Modulus of elasticity (bending)110 GPa110 GPa62 MPa60 MPa
Elongation at breakapprox. 0.5 %approx. 1 %
Compressive strength450 MPa450 MPa
Compressive modulus30 GPa30 GPa
Density1.6 kg/dm³1.65 kg/dm³
Compressive modulus120 GPa30 GPa
IZOD impact strength2,000 kJ/m²30 kJ/m²
Barcol hardness4545
Characteristic value for all types
Interlaminar shear strength

90 MPa

Linear coefficient of thermal expansion

0.1 × 10⁻⁶¹/K

Thermal conductivity

5.2 W/mK

Water absorption

0.10%

Dimensional stability according to Martens

130°C

Carbon fibres

T300
