Standard dimensions
Sizes shown in boldface are typically available from our stock in 6 meter length.
a (mm) | b (mm) | c (mm) | d(mm) |
|---|---|---|---|
25 | 15 | 11 | 3 |
40 | 20 | 10 | 5 |
43 | 43 | 22 | 4 |
45 | 20 | 15 | 4 |
45 | 20 | 15 | 5 |
46 | 32 | 12 | 5 |
114 | 67 | 75 | 8 |
360 | 150 | 260 | 6 |
